Self Priming Pump

Products

Economy Series

  • Products
  • Products

Delux Series

  • Products
  • Products
  • Products

Salient Features

  • Suction lift up to 8 meters
  • TEFC, Capacitor Start and run motor
  • Built in thermal overload protector (TOP) to protect the motor from burning
  • Withstand wide voltage Fluctuations even in economy ranges
  • Double shield ball bearing no need for external lubrication

Application

  • Domestic Use
  • Gardening
  • Pressure Boosting system

Performance Table Download

Tiny Series

Model No. Motor Power KW / HP Pipe Size in mm Mtr H-Head in Meters / Feet
3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48 51 54 57 60
Feet 10 20 30 39 49 59 69 79 89 98 108 118 128 138 147 157 167 177 187 197
SS 11 0.09 / 0.12 15x15 Q Discharge in Lph 1560 1440 1220 1100 930 680 350
SS 21 0.12 / 0.16 20x20 1700 1500 1300 1150 980 780 600 300
SS 31 0.18 / 0.25 20x20 1940 1820 1580 1400 1120 900 650 420

Economy Series

Model No. Motor Power KW / HP Pipe Size in mm Mtr H-Head in Meters / Feet
3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48 51 54 57 60
Feet 10 20 30 39 49 59 69 79 89 98 108 118 128 138 147 157 167 177 187 197
SS 45 0.37 / 0.50 25x25 Q Discharge in Lph 1800 1730 1560 1370 1150 1000 830 640 340
SS 50E 0.37 / 0.50 25x25 2100 1900 1750 1530 1350 1180 1000 780 560 320
SS 51E 0.37 / 0.50 25x25 2200 1960 1780 1600 1400 1250 1080 910 750 550 320
SS 71E 0.75 / 1.0 25x25 3100 2880 2600 2500 2380 2250 2120 1960 1800 1640 1420 1280 1100 1000 800

Delux Series

Model No. Motor Power KW / HP Pipe Size in mm Mtr H-Head in Meters / Feet
3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48 51 54 57 60
Feet 10 20 30 39 49 59 69 79 89 98 108 118 128 138 147 157 167 177 187 197
SS 50 0.37 / 0.50 25x25 Q Discharge in Lph 2250 2000 1750 1550 1380 1200 1050 880 720 560 420
SS 51 0.37 / 0.5 25x25 2750 2600 2380 2180 1960 1740 1530 1340 1140 900 620 400
SS 54 0.75 / 1.0 25x25 3400 3200 3100 2900 2700 2400 2200 1950 1700 1400 1150 800 500
SS 71 1.1 / 1.5 25x25 3600 3130 3100 3080 3020 2960 2880 2780 2600 2400 2150 1980 1780 1650 1400 1160
SS 72 1.10 / 1.5 25x25 3600 3370 3300 3250 3170 3100 3000 2920 2780 2600 2450 2300 2180 2070 1920 1790 1600 1400 1300 1200

Non Self Priming Series

Model No. Motor Power KW / HP Pipe Size in mm Mtr H-Head in Meters / Feet
3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48 51 54 57 60
Feet 10 20 30 39 49 59 69 79 89 98 108 118 128 138 147 157 167 177 187 197
SN 50 0.37 / 0.5 25x25 Q Discharge in Lph 2200 1850 1650 1550 1400 1200 1030 880 730 560 380

240 Volts, 50Hz, AC, Single Phase Supply
