Salient Features
- High quality extruded aluminium motor body
- Double shield ball bearing
- Gun Metal Jet assembly
Application
- Domestic Use
- Gardening
- Borewell Applications
Performance Table Download
| Model No. | Motor Power KW / HP | Pipe Size in mm | Mtr | H-Head in Meters / Feet | |||||||||||||||||||
| 5 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | |||||||||||||||
| Feet | 16 | 33 | 49 | 66 | 82 | 98 | 115 | 131 | 148 | ||||||||||||||
| STJA 1032 | 0.75 / 1.0 | 35x25x25 | Q Discharge in Lph | 2400 | 2300 | 2100 | 1500 | 1000 | 700 | 400 | 200 | ||||||||||||
| STJA 1043 | 0.75 / 1.0 | 40x32x25 | 2450 | 2350 | 2150 | 1550 | 1050 | 750 | 450 | ||||||||||||||
| STJA 1032 2S | 0.75 / 1.0 | 32x25x25 | 1550 | 1450 | 1150 | 1150 | 1150 | 1050 | 900 | 700 | 650 | ||||||||||||
